We stock Stainless Steel, carbon and alloy specialty steels supplied in the as rolled, annealed and normalized conditions. We offer cut to size and heat treatment through our service centre.

We also stock flat, Hexagon, Triangle Bar, Square, Half Round products in various dimensions and grades.We offer a speedy delivery service in order to get your products to you on time.

Application Industries:
Chemicals, Fats, & Fertilizers, Sugar Mills & Distilleries, Cement Industries, Ship Builders, Paper Industries, Pumps, Petrochemicals, Oil & Natural Gas Organization in terms of the specific materials, Technology, Finance & Personal.

Products Range
The following table represents size range, product standards and material grades of Round Bars

Diameter (Size)	Thick / Medium Wire - 1mm to 8mm (0.039" to 0.314") Fine Wire - 0.1mm to 0.9mm (0.004" to 0.035")
Grades	201, 202, 302, 302HQ, 303, 304, 304L, 304Hc, 310, 316, 316L, 316Ti, 321, 304LER, 308LER, 309LER, 316LER, 410, 416, 430, 430L, 430F
Surface finish	Matt, Bright drawn, Bright Shiny, EPQ, Coated, De-coated
Diameter	Diameter	Tolerance
	0.10 mm (0.0039") to<0.20 mm (0.0078") 0.20 mm (0.0078") to < 0.30 mm (0.0118") 0.30 mm (0.0118") to < 0.80 mm (0.0314") 0.80 mm (0.0314") to < 0.50 mm (0.0590") 1.50 mm (0.0590") to < 2.00 mm (0.0787") 2.00 mm (0.0787") to < 4.00 mm (0.1574") 4.00 mm (0.1574") to < 8.00 mm (0.3149")	+/- 0.005 mm (0.0002") +/- 0.008 mm (0.0003") +/- 0.010 mm (0.0004") +/- 0.013 mm (0.0005") +/- 0.015 mm (0.0006") +/- 0.025 mm (0.0009") +/- 0.030 mm (0.0011")
Tensile Strength	Type	Tensile in kg / mm²
	Soft 1/4 Hard 1/2 Hard Full Hard	60 - 75 75 - 90 90 - 140 140 - 200 or ASTM A 313 / DIN 17224
Packing	- HDPE Wrapped coils of 20 kg to 250 kg - Pattern laid coils on MS Carriers / spiders (200 kg to 1000 kg) - Coils on wooden pallets (100 kg to 800 kg) - Cheese coils (500 kg - 1000 kg) - Drum Packing - Fine wire in Spools from Din 80 to Din 250

Condition	Cold drawn, Annealed and Pickled
Diameter (Size)	1.6 mm to 17 mm (1/16" to 11/16")
Diameter Tolerance	+/- 0.050 mm
Tensile Strength	65 kg / mm² max
Packing	HDPE Wrapped coils of 300 kg to 500 kg
Grades	304, 304L, 316, 316L, 304HC, 302HQ
